Access Gate Motor Solutions


By publishing the EN 17352, it has been defined standards for requirements and test methods for power-operated access control devices for the very first time. This includes i.e. turnstiles, swing lanes and retractable lanes. Thus, manufacturers of such products are obliged to take into account further safety requirements when designing new solutions..
Featured Product
GO TO PRODUCTS
Downloads
GO TO DOWNLOADS
EN 17352 Advantages
GO TO ADVANTAGES
Accessgate

Tailored Access Control Motors and Gearboxes for Every Gate Type

DREHKREUZ

Turnstile gearmotor

High torque gearboxes allow robust designs, in case of vandalism or unauthorized access. Depending on lifetime requirements either brushed or brushless motors are advantageous.

BAHNSTEIGAUSSTATTUNG

Speed Gate gearmotor

For swing gates angular gearboxes or planetary gearboxes can be chosen, both available reversible in case of emergency

EINGANGSTREN

Entrance door gearmotor

Brushless motors with integrated or external motor controllers allow smart functions such as impact detection. Slim gearboxes help to minimize the height of e.g. head rails to allow modern designs.


Featured Product

Brushless AC DC

Brushless Motors

Brushless DC motors (also BLDC motor or EC motor) - low-wear, maintenance-free, high efficiency and robust.
Stepper motor - MAE

Stepper Motor

Hybrid Stepper for low speed, high torque applications to provide accurate open loop positioning, or high performances closed loop systems using an integrated encoder.


Your Contact Person

Tobias

Tobias Johnston

Key Account Manager Building Automation

Ametek SRL
Via della Liberazione 24, 26008
Peschiera Borromeo (MI), Italy


Downloads

accessgate

Access gate

download-file

Nexofox

download-file
 Safety parameters according to DIN EN ISO 13849-1

Performance level:                                                        PL d
Category:                                                                      Cat. 3
Diagnostic coverage:                                                    DC low (89,4%)
Mean time to dangerous failure (per channel):               MTTF: 100 years
 Fulfilled standards


DIN EN ISO 13849-1 : 2016-06
Safety of machinery – Safety-related parts of control systems - Part 1: General principles for design/
nexofox:
The nexofox MotionCode allows customer-specific motion profiles that can be freely parameterized according to customer requirements. In addition, nexofox offers further service contents with which, for example, predictive maintenance can be realized.

Here you can find more information about nexofox
nexofox
